Hinged Casing Spider

Size Range:

• 13-3/8″ •  200 Ton Hinged Spider
• 20″ •  200 Ton Hinged Spider
• 30″ •  200 Ton Hinged Spider
• 36″ •  200 Ton Hinged Spider

Supporting Casing: Its primary function is to support and suspend the casing string during casing running operations. The casing string, which consists of individual joints of casing pipe, is lowered into the wellbore to protect, and stabilize the well.
Handling Large Diameter Casing: The tool is designed to handle casing with a diameter of 13-3/8 inches, which is a common size used in oil and gas wells for surface casing or intermediate casing strings.
Hinged Design: The hinged spider casing tool features a hinged mechanism that allows it to open and close around the casing string. This design enables the tool to be easily installed and removed from the casing without having to slide it over the end.
Load Capacity: The tool is rated for a load capacity of 200 tons, indicating its ability to support the weight of the casing string and any additional loads encountered during casing running operations.
Safety and Stability: The hinged spider casing tool provides stability to the casing string during installation, preventing it from buckling or collapsing as it is lowered into the wellbore. This helps ensure the integrity of the well and prevents costly delays or accidents.
Compatibility: The tool is compatible with standard casing running equipment and rig systems commonly used in the oil and gas industry. It can be easily integrated into the casing running operation to facilitate efficient and safe handling of the casing string.

Overall, the 13-3/8" 200 Ton Hinged Spider casing tool plays a critical role in supporting and suspending large diameter casing strings during casing running operations in oil and gas wells, ensuring the integrity and stability of the wellbore. Contact Power Unit Builder & Handling Tools for details.
