Single Joint Elevators SP • SJ

Size Range:

2-3/8" to 30" • 5 Ton

Power Unit Builders & Handling Tools, LLC, specializes in providing high-quality handling tools and equipment for the oil and gas industry. Single joint elevators SP and SJ are components used in the oil and gas industry for handling and lifting tubular goods, such as drill pipes, casing, and tubing, during drilling, completion, and workover operations. These elevators are designed to grip and support the tubulars securely while they are being lifted or lowered into or out of a wellbore.

• Single Joint Elevator SP: Single Joint Elevator SP is a type of elevator primarily used for handling tubular goods in drilling operations. It is designed to grip and lift individual joints of drill pipe, casing, or tubing. These elevators typically have a hinged mechanism that allows them to open and close around the tubular, providing a secure grip for lifting.
• Single Joint Elevator SJ: Single Joint Elevator SJ is another type of elevator used for similar purposes as the SP elevator. It is also designed to handle single joints of drill pipe, casing, or tubing. Like SP elevators, SJ elevators have a mechanism for opening and closing around the tubular to provide a secure grip during lifting operations.

Both SP and SJ elevators are essential tools in the oil and gas drilling industry, contributing to the safe and efficient handling of tubular goods during drilling, completion, and well servicing activities.

---

Here's what a single joint elevator does and how it functions:

Handling Individual Joints: Single joint elevators are designed to lift and lower individual joints of pipe or casing. These joints typically range in length from around 18 feet to over 40 feet, depending on the specific requirements of the drilling operation.
Gripping Mechanism: Single joint elevators typically feature a gripping mechanism that securely holds the pipe or casing joint. This mechanism may consist of jaws or slips tha.t clamp onto the exterior surface of the tubular component, ensuring a firm grip to prevent slippage during lifting or lowering.
Compatibility: Single joint elevators come in various sizes and configurations to accommodate different sizes and types of pipes or casing. They are designed to handle the weight and dimensions of the specific tubular component being lifted.
Integration with Rig Equipment: Single joint elevators are typically integrated into the rig's hoisting system, which includes the derrick, drilling line, and other components used for lifting operations. They are attached to the drilling line and operated manually or remotely, depending on the rig's setup.
Safety Features: Safety is a paramount concern in the oilfield. Single joint elevators are equipped with safety features such as locking mechanisms to prevent accidental release of the tubular component while it is suspended in the air. Additionally, they may have indicators or sensors to detect improper grip or other potential hazards.
Maintenance and Inspection: Like any other equipment on a drilling rig, single joint elevators require regular maintenance and inspection to ensure they are in proper working condition. This helps prevent malfunctions or accidents during lifting operations. Contact Power Unit Builders and Handling Tools, LLC located minutes from Houston, TX for repair and remanufactured needs.

Overall, single joint elevators play a critical role in the safe and efficient handling of individual joints of drill pipe, casing, tubing, and other tubular components in the oilfield, contributing to the overall productivity and safety of drilling and completion operations. Contact Power Unit Builder & Handling Tools for details.
